通風管道是建筑物中用于空氣或氣體傳輸的系統，主要應用于內部通風、空調和排煙系統。其基本構成包括管道、彎頭、三通等部件，材質涵蓋金屬（如鍍鋅鋼板、鋁板、不銹鋼）和非金屬（如玻璃鋼、聚氯乙烯）。

Ventilation ducts are systems used in buildings for the transmission of air or gas, primarily for internal ventilation, air conditioning, and smoke exhaust systems. Its basic components include pipes, elbows, tees, and other parts, with materials ranging from metal (such as galvanized steel plates, aluminum plates, stainless steel) to non-metal (such as fiberglass, polyvinyl chloride).

通風管道的設計和安裝需考慮建筑物結構、使用功能、人員密度和氣候環境。設計階段涉及確定需求、選擇材料和布局規劃；安裝階段包括準備工作、測量標記、主干管和分支管安裝、檢查調整以及驗收測試，確保管道質量和安全性，避免漏風、震動等問題，最終實現通風管道系統的高效運行。

The design and installation of ventilation ducts need to consider building structure, functional use, personnel density, and climate environment. The design phase involves determining requirements, selecting materials, and layout planning; The installation phase includes preparation work, measurement marking, installation of main and branch pipes, inspection and adjustment, and acceptance testing to ensure the quality and safety of the pipeline, avoid problems such as air leakage and vibration, and ultimately achieve efficient operation of the ventilation duct system.

通風管道按外形分為圓形和矩形，按材質分為普通薄鋼板、鍍鋅薄鋼板、不銹鋼板等。 通風管道的尺寸設計應根據風量要求和運行壓力確定，直徑或截面尺寸應滿足設計要求。安裝規范包括垂直或水平安裝、密封連接、牢固支架等。

Ventilation ducts are divided into circular and rectangular shapes according to their appearance, and into ordinary thin steel plates, galvanized thin steel plates, stainless steel plates, etc. according to their materials. The size design of ventilation ducts should be determined based on the air volume requirements and operating pressure, and the diameter or cross-sectional size should meet the design requirements. Installation specifications include vertical or horizontal installation, sealed connections, and secure brackets.

干貨來了~給排水、消防、暖通CAD圖例符號大全與畫法_管道干貨來了~給排水、消防、暖通CAD圖例符號大全與畫法_管道在防火方面，通風管道應采用具有一定防火性能的材料，如鍍鋅鋼板、不銹鋼板等金屬材料，或者防火性能達到一定標準的玻璃鋼、復合材料等。 對于一些防火要求較高的部位或穿越防火分區的通風管道，可以采用防火材料對管道進行包裹，如防火巖棉、防火板等，提高管道的耐火性能。

Dry goods have arrived~Complete list and drawing methods of CAD legend symbols for water supply and drainage, fire protection, and HVAC _ Pipeline dry goods have arrived~Complete list and drawing methods of CAD legend symbols for water supply and drainage, fire protection, and HVAC _ Pipeline In terms of fire prevention, ventilation ducts should use materials with certain fire resistance properties, such as galvanized steel plates, stainless steel plates and other metal materials, or fiberglass, composite materials with certain fire resistance standards. For areas with high fire protection requirements or ventilation ducts that pass through fire compartments, fire-resistant materials such as fire-resistant rock wool, fire-resistant boards, etc. can be used to wrap the ducts to improve their fire resistance performance.

風管包覆防火板 防火隔墻防火板 纖維增強硅酸鹽防 …風管包覆防火板 防火隔墻防火板 纖維增強硅酸鹽防 …通風管道的安裝還需遵循國家和地方規范標準，如《建筑通風與空氣調節設計規范》，并制定詳細的施工方案。安裝過程中需保證管道密封性、穩固性和防火性，避免過長或過曲。

The installation of ventilation ducts also needs to comply with national and local standards, such as the "Code for Design of Building Ventilation and Air Conditioning", and develop detailed construction plans. During the installation process, it is necessary to ensure the sealing, stability, and fire resistance of the pipeline, and avoid excessive length or curvature.

管道風機安裝示意圖,消防排煙風機安裝圖片(2) - 傷感說說吧管道風機安裝示意圖,消防排煙風機安裝圖片(2) - 傷感說說吧通風管道在建筑工程中的應用需要綜合考慮設計、材料選擇、尺寸設計、安裝規范和防火措施等多個方面，以確保其穩定性和安全性。

Installation diagram of pipeline fan, installation picture of fire smoke exhaust fan (2) - Sad Talk Bar Installation diagram of pipeline fan, installation picture of fire smoke exhaust fan (2) - Sad Talk Bar The application of ventilation ducts in building engineering requires comprehensive consideration of design, material selection, size design, installation specifications, and fire prevention measures to ensure their stability and safety.
